FAG double row angular contact ball bearing designed for applications requiring combined radial and axial load support. Available in multiple configurations with different inner diameters, outer diameters, widths and 30° or 45° contact angles. Select the required bearing size and specification from the available options.
This page carries FAG double row angular contact ball bearings across thirteen bore sizes - from a compact 20 mm bearing up to an 80 mm heavy-duty size. Instead of stocking one fixed bearing, we've set it up so you choose the dimensions your machine actually needs: inner diameter, outer diameter, width, and contact angle. Pick those, and the exact FAG designation, current price and stock status update to match.
Two FAG series sit behind this range. The 32-series covers FAG 3204-BD-XL-TVH-L285 through FAG 3216-B-TVH, bore sizes 20 mm to 80 mm. The 33-series is a heavier cross-section for the same bore range, from FAG 3304-BD-XL-TVH-L285 to FAG 3313-BD-XL-TVH-L285, bore sizes 20 mm to 65 mm. Nearly everything here runs a polyamide cage (that's the TVH in the designation) at a 30-degree contact angle - the one exception is the FAG 3311-BD-XL-TVH-L285, built at 45 degrees. Orders go out from our Ahmedabad warehouse with a GST invoice, and if you're not sure which size fits your application, our team can confirm it over WhatsApp before you order.
Key Features
Genuine FAG double row angular contact ball bearings, sold under the exact designation printed on the bearing
Bore sizes from 20 mm to 80 mm across two FAG series (32-series and 33-series)
30-degree contact angle across most of the range, plus a 45-degree option on the FAG 3311-BD-XL-TVH-L285
Polyamide (TVH) cage construction throughout the range
HSN code 84822011 for GST-compliant billing
Dispatched from Ahmedabad with a GST invoice and support to confirm your exact size
Configurable product – multiple bore sizes on one listing
Bearing Type
Double Row Angular Contact Ball Bearing
Inner Diameter Range
20 mm – 80 mm
Outer Diameter Range
47 mm – 140 mm
Width Range
20.6 mm – 58.7 mm
Contact Angle
30 Degree, 45 Degree
Cage Material
Polyamide (TVH)
HSN Code
84822011
Availability
In Stock
Understanding the Configurable Options
Inner Diameter
Inner diameter is simply the size of the hole running through the centre of the bearing - it decides which shaft the bearing will sit on. Sizes here run 20 mm to 80 mm.
Outer Diameter
Outer diameter is the bearing's outside edge, and it's the measurement that has to match your housing or mounting bore. Across this range it goes from 47 mm to 140 mm.
Width
Then there's width - how thick the bearing is, face to face. This one governs axial clearance: get it wrong and the bearing either won't seat properly or binds against the shaft shoulder. Widths here span 20.6 mm to 58.7 mm depending on the size you pick.
Contact Angle
Contact angle is a bit more technical: it's the angle at which load passes from the balls to the raceways. Because this is a double row bearing, that angle sits on both rows, which is exactly what lets it carry radial and axial load together, from either direction. Most sizes on this page run 30 degrees; the FAG 3311-BD-XL-TVH-L285 is the one built at 45 degrees.
Worth knowing before you select: the same inner diameter can turn up in both FAG series, with a different outer diameter and width each time. A 30 mm bore, for instance, is available as the FAG 3206-BD-XL-TVH-L285 (30 x 62 x 23.8 mm) or the FAG 3306-BD-XL-TVH-L285 (30 x 72 x 30.2 mm) - two different bearings. Check inner diameter, outer diameter and width together, not the bore size on its own, before you place an order.
Available FAG Double Row Angular Contact Ball Bearing Sizes
32-Series: FAG 3204 to FAG 3216 (30-degree contact angle)
Bearing Designation
Inner Diameter
Outer Diameter
Width
FAG 3204-BD-XL-TVH-L285
20 mm
47 mm
20.6 mm
FAG 3205-BD-XL-TVH-L285
25 mm
52 mm
20.6 mm
FAG 3206-BD-XL-TVH-L285
30 mm
62 mm
23.8 mm
FAG 3207-BD-XL-TVH-L285
35 mm
72 mm
27 mm
FAG 3208-BD-XL-TVH-L285
40 mm
80 mm
30.2 mm
FAG 3209-BD-XL-TVH-L285
45 mm
85 mm
30.2 mm
FAG 3210-BD-XL-TVH-L285
50 mm
90 mm
30.2 mm
FAG 3211-BD-XL-TVH-L285
55 mm
100 mm
33.3 mm
FAG 3212-BD-XL-TVH-L285
60 mm
110 mm
36.5 mm
FAG 3213-BD-XL-TVH-L285
65 mm
120 mm
38.1 mm
FAG 3214-B-TVH
70 mm
125 mm
39.7 mm
FAG 3215-B-TVH
75 mm
130 mm
41.3 mm
FAG 3216-B-TVH
80 mm
140 mm
44.4 mm
33-Series: FAG 3304 to FAG 3313 (heavier cross-section)
Bearing Designation
Inner Diameter
Outer Diameter
Width
FAG 3304-BD-XL-TVH-L285
20 mm
52 mm
22.2 mm
FAG 3305-BD-XL-TVH-L285
25 mm
62 mm
25.4 mm
FAG 3306-BD-XL-TVH-L285
30 mm
72 mm
30.2 mm
FAG 3307-BD-XL-TVH-L285
35 mm
80 mm
34.9 mm
FAG 3308-BD-XL-TVH-L285
40 mm
90 mm
36.5 mm
FAG 3309-BD-XL-TVH-L285
45 mm
100 mm
39.7 mm
FAG 3310-BD-XL-TVH-L285
50 mm
110 mm
44.4 mm
FAG 3311-BD-XL-TVH-L285 *
55 mm
120 mm
49.2 mm
FAG 3312-BD-XL-TVH-L285
60 mm
130 mm
54 mm
FAG 3313-BD-XL-TVH-L285
65 mm
140 mm
58.7 mm
* 45-degree contact angle. All other sizes in both tables above are 30-degree.
How to Choose the Right FAG Bearing
Measure the shaft the bearing needs to sit on - that's your inner diameter.
Measure the housing or mounting bore it needs to fit into - that's your outer diameter.
Work out the axial space you have available - that's your width.
Decide whether your application calls for a 30-degree or 45-degree contact angle.
Match these against the FAG designation shown on this page - remember, one bore size can show up in two different series.
Before ordering, cross-check the designation against your machine manufacturer's spec or the bearing you're replacing.
Applications
Wherever a bearing has to carry radial load and axial load at the same time, a double row angular contact design is usually in the running. That covers a fair spread of equipment:
Machine tool spindles and rotary tables
Gearboxes and speed reducers
Pumps and general rotating industrial equipment
Electric motors and material handling systems
The bigger sizes in this range work harder for a living. The FAG 3313-BD-XL-TVH-L285 and FAG 3216-B-TVH are built for continuous heavy duty - extruders, mining equipment, marine drives, turbines, large industrial gearboxes and similar.
Why Choose a Double Row Angular Contact Design
Two rows of balls, set at an angle to the axis instead of straight across - that's the whole trick. It's what lets a single bearing carry radial load and axial load from both directions, which a standard deep groove ball bearing simply isn't built to do. There's a space advantage too: one double row bearing does the job of two single row angular contact bearings mounted back-to-back, without needing the extra axial room that pairing usually eats up. Combined-load capacity plus a compact footprint is exactly why this design shows up so often in equipment where space is tight but the loads aren't simple.
FAG Bearing Designation Explained
We show every size here under its full FAG designation, exactly as it's marked on the bearing itself - nothing shortened or simplified. Two series make up this range:
32-series - FAG 3204-BD-XL-TVH-L285 through FAG 3216-B-TVH, 20 mm to 80 mm bore
33-series - FAG 3304-BD-XL-TVH-L285 through FAG 3313-BD-XL-TVH-L285, 20 mm to 65 mm bore
TVH is the one suffix we can tell you about with confidence: it denotes the polyamide cage used throughout this range. BD, XL, L285 and B are FAG's own internal design and material codes, and rather than guess at what each one means, we'd rather give you the complete designation as FAG issues it, so you can match it against your machine manual or the old bearing directly.
Compatibility & Replacement
Replacing an existing bearing? Match all of these before you order, not just one or two:
Bearing designation, if it's still visible on the old one
Inner diameter
Outer diameter
Width
Contact angle
Your machine manufacturer's bearing specification
Everything on this page is genuine FAG. We haven't checked how these cross over with SKF, NSK, NTN, Timken or other brands, so treat this as a FAG-to-FAG match and confirm against your machine's documentation rather than assuming a straight swap will work.
Buying FAG Double Row Angular Contact Ball Bearings from SparesZone
Every size shown here is genuine FAG stock. Select your inner diameter, outer diameter, width and contact angle, and price and availability update right away - no need to open a separate listing. Orders ship with a GST invoice, and if you'd rather get a formal quotation before committing to purchase, use Request a Quote instead of adding straight to cart.
Why Buy From SparesZone
Industrial spare parts supplier based in Ahmedabad, Gujarat
Multiple FAG bearing sizes on one page, so you compare and select without switching listings
Full specifications shown for every size before you order
GST-registered supplier (GSTIN 24AFSFS3212F1Z2) with proper invoicing
WhatsApp support to confirm the correct size or designation before you buy
Frequently Asked Questions
Picture two rows of balls, each sitting at an angle to the bearing's axis rather than straight across it. That's the design, and it's what lets one compact bearing carry radial load and axial load in both directions, instead of needing a second bearing alongside it.
Thirteen bore sizes, 20 mm to 80 mm, split across two FAG series: the 32-series (FAG 3204-BD-XL-TVH-L285 to FAG 3216-B-TVH) and the 33-series (FAG 3304-BD-XL-TVH-L285 to FAG 3313-BD-XL-TVH-L285). Select your inner diameter, outer diameter and width and the exact designation and price will show.
Inner diameter is the bore - the hole the shaft passes through. Outer diameter is the other end of the bearing, the measurement that has to match your housing or mounting bore. Get either one wrong and the bearing just won't fit.
It's the bearing's thickness, measured face to face along the shaft. Width decides how much axial room the bearing takes up once installed, so it needs to match the space you've actually got in your assembly.
It's the angle load travels through as it passes from the balls to the raceways - a steeper angle means more axial (thrust) capacity. Most sizes here run 30 degrees; the FAG 3311-BD-XL-TVH-L285 is the exception, built at 45 degrees.
Select your inner diameter, outer diameter and width on this page and the matching designation, price and availability appear automatically. Worth knowing: the same bore size sometimes falls in both FAG series with a different outer diameter and width, so check all three measurements together rather than the bore alone.
Yes, on both counts. Every size on this page is genuine FAG stock, and orders go out from our Ahmedabad warehouse with a GST invoice (GSTIN 24AFSFS3212F1Z2).
You can, as long as the inner diameter, outer diameter, width and contact angle line up with what you're replacing - ideally your machine manufacturer's spec too. We haven't checked cross-brand interchange with SKF, NSK, NTN, Timken or others, so treat this as FAG-to-FAG matching rather than an assumed swap.
Not sure which inner diameter, outer diameter, width or contact angle matches your application? Share your requirement or the bearing you are replacing, and our team will confirm the correct FAG designation before you order.
