GMC UCAP GMC Pillow Block Bearing With Bore Housing Unit
As low as
₹290.40
was
₹396.00
| Model | Overall height | Housing overall width | Centre distance between bolt holes | Bearing width, total |
|---|---|---|---|---|
| GMC UCAP 204 | 62 mm | 40 mm | 52 mm | 31 mm |
| GMC UCAP 205 | 72 mm | 38 mm | 56 mm | 34 mm |
| GMC UCAP 206 | 84 mm | 50 mm | 66 mm | 38.1 mm |
| GMC UCAP 207 | 95 mm | 55 mm | 80 mm | 42.9 mm |
| GMC UCAP 208 | 100 mm | 58 mm | 84 mm | 49.2 mm |
| GMC UCAP 209 | 108 mm | 60 mm | 90 mm | 49.2 mm |
| GMC UCAP 210 | 116 mm | 64 mm | 94 mm | 51.6 mm |
Availability:
In stock
Only %1 left
SKU
GMC-UCAP-P-B-BRNG
Product Overview
The GMC UCAP Pillow Block Bearing Series represents GMC's premium tapped-base pillow block line from 20 mm to 50 mm bore sizes.
Available Sizes
| Model | Inner Dia | Height | Width | Pitch | Brg Width |
|---|---|---|---|---|---|
| GMC UCAP 204 | 20 mm | 62 mm | 40 mm | 52 mm | 31.0 mm |
| GMC UCAP 205 | 25 mm | 72 mm | 38 mm | 56 mm | 34.0 mm |
| GMC UCAP 206 | 30 mm | 84 mm | 50 mm | 66 mm | 38.1 mm |
| GMC UCAP 207 | 35 mm | 95 mm | 55 mm | 80 mm | 42.9 mm |
| GMC UCAP 208 | 40 mm | 100 mm | 58 mm | 84 mm | 49.2 mm |
| GMC UCAP 209 | 45 mm | 108 mm | 60 mm | 90 mm | 49.2 mm |
| GMC UCAP 210 | 50 mm | 116 mm | 64 mm | 94 mm | 51.6 mm |
| Brand | GMC |
|---|
