UCAP Pillow Block Bearing With Housing Unit

As low as ₹290.40 was ₹396.00

Model	Overall height	Housing overall width	Centre distance between bolt holes	Bearing width, total
UCAP 204	62 mm	40 mm	52 mm	31 mm
UCAP 205	72 mm	38 mm	56 mm	34 mm
UCAP 206	84 mm	50 mm	66 mm	38.1 mm
UCAP 207	95 mm	55 mm	80 mm	42.9 mm
UCAP 208	100 mm	58 mm	84 mm	49.2 mm
UCAP 209	108 mm	60 mm	90 mm	49.2 mm
UCAP 210	116 mm	64 mm	94 mm	51.6 mm

Availability:

In stock

Only %1 left

SKU

UCAP-P-B-BRNG

The UCAP Pillow Block Bearing With Housing Unit Series provides a versatile, compact tapped-base solution across 20 mm to 50 mm shaft sizes.

Model	Inner Dia	Height	Width	Pitch	Brg Width
UCAP 204	20 mm	62 mm	40 mm	52 mm	31.0 mm
UCAP 205	25 mm	72 mm	38 mm	56 mm	34.0 mm
UCAP 206	30 mm	84 mm	50 mm	66 mm	38.1 mm
UCAP 207	35 mm	95 mm	55 mm	80 mm	42.9 mm
UCAP 208	40 mm	100 mm	58 mm	84 mm	49.2 mm
UCAP 209	45 mm	108 mm	60 mm	90 mm	49.2 mm
UCAP 210	50 mm	116 mm	64 mm	94 mm	51.6 mm
