UCFL Cartridge Pillow Block Bearing Unit with Housing (20mm - 75mm Bore)

Be the first to review this product

As low as ₹237.60 was ₹345.60

Model	Overall height	Distance between bolts	Overall length	Bearing width, total	Inner diameter
UCFL 204	113 mm	90 mm	60 mm	31 mm	20 mm
UCFL 205	113 mm	99 mm	68 mm	34 mm	25 mm
UCFL 206	147.5 mm	117 mm	80 mm	38.1 mm	30 mm
UCFL 207	161 mm	130 mm	90 mm	42.9 mm	35 mm
UCFL 208	174.5 mm	144 mm	100 mm	49.2 mm	40 mm
UCFL 209	188 mm	148 mm	108 mm	49.2 mm	45 mm
UCFL 210	197 mm	157 mm	115 mm	51.6 mm	50 mm
UCFL 211	224 mm	184 mm	30 mm	55.6 mm	55 mm
UCFL 212	250 mm	202 mm	140 mm	65.1 mm	60 mm
UCFL 213	258 mm	210 mm	155 mm	65.1 mm	65 mm
UCFL 214	265 mm	216 mm	160 mm	68.3 mm	70 mm
UCFL 215	275 mm	225 mm	64 mm	78.8 mm	75 mm

Availability:

In stock

Only %1 left

SKU

UCFL-PARENT

Details

Product Overview

The UCFL Pillow Block Bearing Series offers cast iron pillow block mounted units across shaft sizes from 20 mm to 75 mm.

Available Sizes & Specifications

Model	Overall height	Distance between bolts	Overall length	Bearing width, total	Inner diameter
UCFL 204	113 mm	90 mm	60 mm	31 mm	20 mm
UCFL 205	113 mm	99 mm	68 mm	34 mm	25 mm
UCFL 206	147.5 mm	117 mm	80 mm	38.1 mm	30 mm
UCFL 207	161 mm	130 mm	90 mm	42.9 mm	35 mm
UCFL 208	174.5 mm	144 mm	100 mm	49.2 mm	40 mm
UCFL 209	188 mm	148 mm	108 mm	49.2 mm	45 mm
UCFL 210	197 mm	157 mm	115 mm	51.6 mm	50 mm
UCFL 211	224 mm	184 mm	30 mm	55.6 mm	55 mm
UCFL 212	250 mm	202 mm	140 mm	65.1 mm	60 mm
UCFL 213	258 mm	210 mm	155 mm	65.1 mm	65 mm
UCFL 214	265 mm	216 mm	160 mm	68.3 mm	70 mm
UCFL 215	275 mm	225 mm	64 mm	78.8 mm	75 mm

Applications

Conveyors, industrial machinery, packaging equipment, fans, and bulk material systems.
