UCFC Round Flange Cartridge Pillow Block Bearing Unit with Housing (20mm - 75mm Bore)

Be the first to review this product

As low as ₹334.40 was ₹486.40

Model	Overall height	Bolt hole centre distance	Bearing width, total	Inner diameter
UCFC 204	100 mm	55.2 mm	31 mm	20 mm
UCFC 205	115 mm	63.6 mm	34 mm	25 mm
UCFC 206	125 mm	70.7 mm	38.1 mm	30 mm
UCFC 207	135 mm	77.8 mm	42.9 mm	35 mm
UCFC 208	145 mm	84.5 mm	49.2 mm	40 mm
UCFC 209	160 mm	93.3 mm	49.2 mm	45 mm
UCFC 210	165 mm	97.2 mm	51.6 mm	50 mm
UCFC 211	185 mm	106.1 mm	55.6 mm	55 mm
UCFC 212	195 mm	113.1 mm	65.1 mm	60 mm
UCFC 213	205 mm	120.2 mm	65.1 mm	65 mm
UCFC 214	215 mm	125.2 mm	68.3 mm	70 mm
UCFC 215	220 mm	130.1 mm	77.8 mm	75 mm

Availability:

In stock

Only %1 left

SKU

UCFC-PARENT

Details

Product Overview

The UCFC Round Flange Bearing Series offers precision 4-bolt round cartridge units across 20 mm to 75 mm sizes.

Available Sizes

Model	Height	Pitch	Width	Inner Dia
UCFC 204	100 mm	55.2 mm	31 mm	20 mm
UCFC 205	115 mm	63.6 mm	34 mm	25 mm
UCFC 206	125 mm	70.7 mm	38.1 mm	30 mm
UCFC 207	135 mm	77.8 mm	42.9 mm	35 mm
UCFC 208	145 mm	84.5 mm	49.2 mm	40 mm
UCFC 209	160 mm	93.3 mm	49.2 mm	45 mm
UCFC 210	165 mm	97.2 mm	51.6 mm	50 mm
UCFC 211	185 mm	106.1 mm	55.6 mm	55 mm
UCFC 212	195 mm	113.1 mm	65.1 mm	60 mm
UCFC 213	205 mm	120.2 mm	65.1 mm	65 mm
UCFC 214	215 mm	125.2 mm	68.3 mm	70 mm
UCFC 215	220 mm	130.1 mm	77.8 mm	75 mm
