BOCHU Laser Consumables in India - Ceramic Rings, Protective Lens & Focus/Collimating Lens
SparesZone stocks genuine BOCHU consumables for BOCI BLT-series fiber laser cutting heads - ceramic rings, protective lens (protective windows) and focus & collimating lens. If your machine runs a BOCHU control system with a BOCI BLT head, these are the three parts you will be reordering the most, and every piece we sell is original-grade and checked before it ships.
BOCI heads are precision-built, and their consumables come in specific diameter and height combinations that are easy to get wrong from memory. A ceramic ring that is 0.5mm off in height, or a protective lens with the wrong thickness for your power rating, will still physically fit - but it will not perform, and it can damage the optics above it. We would rather confirm the exact size with you than sell you the wrong one.
Not sure which size your head takes? WhatsApp a photo of the part (or the old one you are replacing) to +91 92740 95891 and we will match it before you order.
BOCHU - Company Overview
BOCHU builds two things that matter to a fiber laser workshop: the control system (the FSCUT range of CNC controllers that run the machine's motion, laser and gas) and the cutting head - sold under the BOCI brand as the BLT series. On a lot of Indian-assembled and Chinese-imported fiber laser machines, you will find a BOCHU controller and a BOCI BLT head working together, which is why the two names come up interchangeably in the market.
The BLT range runs from lighter BLT3/BLT4-class heads for everyday 2D sheet cutting up through high-power BLT6/BLT8/BLT9-class heads for thick plate, plus dedicated tube-cutting variants. Every one of these heads uses the same three consumable categories underneath - a ceramic ring to isolate and sense, a protective lens to guard the optics, and a focus/collimating lens to actually shape the beam. That is exactly what we stock.
BOCHU Consumables We Stock
- Ceramic rings - including the M11 thread ring (40.8 mm diameter) for standard sheet-cutting heads and the M8 thread ring (20 mm diameter) built for pipe and tube cutting heads.
- Protective lens - a full size range from 1.5x20 mm up to 4x22.35 mm and beyond, covering both low-power and higher-power BLT heads.
- Focus & collimating lens - the optics that actually focus and collimate the beam inside the head, matched to your BLT model.
If you already know your head model, tell us and we will shortlist the right parts instead of you scrolling through every size. +91 92740 95891 on WhatsApp.
BOCHU Ceramic Rings
The ceramic ring sits directly behind the nozzle and does a job that is easy to overlook until it fails: it electrically isolates the nozzle from the head body and carries the capacitive height-sensing signal that keeps the head at a constant standoff from the sheet. A cracked, chipped or carbon-tracked ceramic shows up as an "unstable signal" fault or erratic height following long before anyone thinks to check it - so it is worth keeping a spare on the shelf rather than discovering the problem mid-shift.
| Part | Thread | Diameter | Typical Use |
|---|---|---|---|
| BOCHU Ceramic Ring | M11 | 40.8 mm | Standard sheet-cutting BLT heads |
| BOCHU Ceramic Ring (Tube) | M8 | 20 mm | Pipe / tube cutting BLT heads |
A quick way to check which one you need: measure the thread on the old ring, or match it against the nozzle you are currently running - M11 and M8 nozzles will not thread onto the wrong ceramic. Browse ceramic rings →
BOCHU Protective Lens
Think of the protective lens as a sacrificial disc. Every spark and bit of molten spatter that comes back up through the nozzle hits this window first, not your focus lens. On a machine cutting mild steel for most of the day, that window can go hazy or pitted within a shift or two - and once it starts absorbing power instead of transmitting it, cut quality drops before anyone notices why.
The power rating matters as much as the size - a lens built for a 10KW head will not survive long on a 20KW machine, even if the physical dimensions happen to match. Here is the full range we stock, grouped by power class:
| Power Class | Available Sizes (Height x Diameter) |
|---|---|
| Standard range | 1.5x20, 2x18, 2x20, 2x25, 2x27, 2x30, 2x32, 3x20, 3x25, 3x34, 4x20, 4x22.35, 4.1x27.9 mm |
| 10 KW | 1.5x24.9, 2x21.5, 5x34, 5x36, 7x37 mm |
| 12 KW | 3x36, 4x35 mm |
| 15 KW | 1.5x24.9, 1.5x55, 1.6x37, 1.6x38.1, 2x21.5, 2x38, 2x40, 2.5x40, 3.5x37, 4x50, 5x34, 5x36, 5x37, 5x40, 7x37, 7x40 mm |
| 20 KW | 3x100, 7x37 mm |
Sizes repeat across power classes (for example 5x36 mm exists in both the 10KW and 15KW range) - so always confirm the power rating along with the dimension, not the size alone. If you are unsure which power class your head is built for, send us the model or a photo and we will match it exactly. Browse protective lens →
BOCHU Focus & Collimating Lens
The collimating lens straightens the beam coming out of the fiber, and the focus lens brings that beam to a point at the cutting surface - together they are the core optics inside a BOCI BLT head. Unlike the ceramic ring or protective lens, these are sold specific to the head model, not by a generic size chart, so it matters to know exactly which BLT head you are running before ordering.
We stock lenses for the following BLT heads, with focusing and collimating lens available separately or as a matched set:
| Head Model | Lens Type | Focal Length | Diameter |
|---|---|---|---|
| BLT310 | Focusing Lens | 200 mm | 32 mm |
| BLT310 | Collimating Lens | 100 mm | 32 mm |
| BLT310 | Focusing & Collimating Lens (Set) | - | 32 mm |
| BLT421s | Focusing Lens | 150 mm | 32 mm |
| BLT421s | Focusing Lens | 200 mm | 32 mm |
| BLT421s | Collimating Lens | 100 mm | 32 mm |
| BLT421s | Focusing & Collimating Lens (Set) | - | 32 mm |
Note the BLT421s comes in two focusing-lens focal lengths (150 mm and 200 mm) - these are not interchangeable, so confirm which one your head takes before ordering rather than going by diameter alone. If you are not sure whether you need the focusing lens, the collimating lens, or the combined set, tell us your head model and we will confirm. Browse focus & collimating lens →
BOCHU Consumable Maintenance Guide
- Protective lens: check every shift on heavy mild-steel work. Replace at the first haze, pitting or spatter that will not wipe off.
- Ceramic ring: replace if cracked, chipped, or if you see height-signal instability. Re-seat firmly after fitting - a loose ceramic can mimic a sensor fault.
- Focus & collimating lens: inspect whenever you change the protective window, since they sit right above it. Replace at any sign of contamination, thermal lensing (focus drift) or a drop in cut speed with no other cause.
- Handling: change consumables in a clean area, never touch the optic face directly, and use a lint-free wipe with the correct solvent. Most "bad lens" complaints trace back to careless handling during a swap, not the part itself.
BOCHU / BOCI Troubleshooting Guide
| Symptom | Likely Cause | Fix |
|---|---|---|
| Rough or striated cut face | Hazed protective lens absorbing power | Replace the protective lens first |
| Cut speed dropping over time | Contaminated focus/collimating lens or window | Replace protective lens; inspect focus lens if it persists |
| Erratic height following | Cracked or carbon-tracked ceramic ring | Replace ceramic; re-seat firmly |
| "Unstable signal" fault | Ceramic or nozzle not seated correctly | Re-seat nozzle & ceramic; replace ceramic if damaged |
Rule of thumb: cut-quality issues, start with the protective lens. Height/signal issues, start with the ceramic ring.
Why Buy BOCHU Parts from SparesZone?
- Original-grade only - ceramic rings, protective lens and focus/collimating lens matched to your BLT head, not generic look-alikes.
- Size confirmed before you order - send a photo or the old part's dimensions and we match it exactly.
- GST invoice on every order (GSTIN 24AFSFS3212F1Z2).
- Same-day dispatch from Ahmedabad, pan-India delivery in 1-3 business days.
Frequently Asked Questions
BOCI BLT heads use the same three wear parts as most fiber laser heads: a ceramic ring (isolation and height sensing), a protective lens (guards the optics from spatter) and a focus/collimating lens (shapes the beam). SparesZone stocks all three for BOCHU-based machines.
The M11 ceramic ring (40.8 mm) is built for standard sheet-cutting BLT heads, while the M8 ceramic ring (20 mm) is sized for pipe and tube-cutting heads. They are not interchangeable - match the thread to your head, not by appearance.
It depends on material and cutting parameters, but on a busy machine cutting mild steel, expect anywhere from daily to a couple of times a week. Replace it at the first sign of haze, pitting or spatter that will not clean off - a degraded window absorbs power and can damage the focus lens above it.
We stock a full range by height and diameter - from 1.5x20 mm up to 4x22.35 mm, including 2x25, 2x27, 2x30, 2x32 and 3x34 mm variants. Match the size to your existing window, or send us the measurement and we will confirm.
BOCHU is the parent company, known for its laser cutting control systems (the FSCUT range). BOCI is the cutting head brand within the BOCHU ecosystem - the BLT-series heads. In the market the two names are often used interchangeably for the same product line.
The quickest way is to WhatsApp a photo of your current part (or your head model) to +91 92740 95891. We will confirm the exact ceramic thread, protective lens size or focus lens spec before you order, so you are not stuck with the wrong part.
