UCFC 210 Round Flange Bearing Unit (50mm Bore x 165mm Height x 97.2mm Bolt Center x 51.6mm Width)

was ₹1,177.60 Special Price ₹809.60
UCFC 210 round flange bearing unit with 50 mm bore for conveyors and industrial machinery
Complete unit with housing and insert bearing: 165 mm height, 97.2 mm bolt centre, 51.6 mm width
Standard UCFC 210 size; match the 50 mm bore to your shaft and the bolt pattern to your frame
Availability:
In stock
SKU
UCFC-210

UCFC 210 Round Flange Bearing Unit (50mm Bore x 165mm Height x 97.2mm Bolt Center x 51.6mm Width)

The UCFC 210 Round Flange Bearing Unit accommodates 50 mm shafts, providing maximum rigidity.

This product is part of the UCFC Round Flange Cartridge Pillow Block Bearing Unit with Housing (20mm - 75mm Bore) range: Inner Diameter 50 mm.

The UCFC Round Flange Bearing Series offers precision 4-bolt round cartridge units across 20 mm to 75 mm sizes.

Key Features of the UCFC 210 Round Flange Bearing Unit (50mm Bore x 165mm Height x 97.2mm Bolt Center x 51.6mm Width)

  • Inner Diameter: 50 mm
  • Standard ISO dimensions for a correct fit
  • Smooth, reliable rotation under load
  • Easy replacement using the size designation

UCFC 210 Round Flange Bearing Unit (50mm Bore x 165mm Height x 97.2mm Bolt Center x 51.6mm Width) Specifications

Parameter Value
Inner Diameter 50 mm
Manufacturer GMC
Overall height 165 mm
Bolt hole centre distance 97.2 mm
Bearing width, total 51.6 mm
Housing Material Cast Iron
HSN Code 84832090
Model UCFC 210
Height 165 mm
Pitch 97.2 mm
Width 51.6 mm
SKU UCFC-210

Available Options in this Range

Inner Diameter SKU
20 mm UCFC-204
25 mm UCFC-205
30 mm UCFC-206
35 mm UCFC-207
40 mm UCFC-208
45 mm UCFC-209
50 mm UCFC-210 This product
55 mm UCFC-211
60 mm UCFC-212
65 mm UCFC-213
70 mm UCFC-214
75 mm UCFC-215

Applications & Industries

  • Conveyor systems
  • Agricultural machinery
  • Packaging machines
  • Textile machinery
  • Pumps, fans and blowers
  • General industrial equipment

Benefits of the UCFC 210 Round Flange Bearing Unit (50mm Bore x 165mm Height x 97.2mm Bolt Center x 51.6mm Width)

Features

Industrial bearing made to standard ISO dimensions (bore, outside diameter and width) for a correct fit on shaft and housing.

Benefits

Smooth rotation, reliable load support and easy replacement using the standard size designation.

How to Choose the Right Option

  1. Confirm you need this option (Inner Diameter 50 mm) - compare it with the other options in the table above.
  2. Match the bore (inner diameter) to your shaft size.
  3. Check the outside diameter and width (or housing dimensions) against the mounting space.
  4. Copy the full designation, including any suffix, from the old bearing before ordering.
  5. Choose a sealed version where dust or moisture is present.

Why Choose Us

  • Ready stock with fast dispatch across India
  • Bulk pricing for industrial and B2B buyers
  • Quality-checked products for continuous industrial use
  • Expert support for product selection and compatibility
  • Trusted supplier for industrial laser spares and consumables

Frequently Asked Questions

Inner Diameter: 50 mm; Manufacturer: GMC; Overall height: 165 mm; Bolt hole centre distance: 97.2 mm; Bearing width, total: 51.6 mm; Housing Material: Cast Iron; HSN Code: 84832090; Model: UCFC 210; Height: 165 mm; Pitch: 97.2 mm; Width: 51.6 mm.

The range has 12 options. See the Available Options table on this page and choose the one that matches your requirement.

Read the designation on the old bearing, or measure the bore, outside diameter and width and match them to the options on this page.

The price depends on quantity. Bulk buyers can request a quote for the best pricing.

Yes, bulk quantities are available with competitive pricing and delivery across India.
