UCAP 206 Pillow Block Bearing With 30mm Bore Housing Unit
was
₹528.00
Special Price
₹387.20
| Overall height | 84 mm |
| Housing overall width | 50 mm |
| Centre distance between bolt holes | 66 mm |
| Bearing width, total | 38.1 mm |
Availability:
In stock
SKU
UCAP-206-P-B-BRNG
Product Overview
The UCAP 206 Pillow Block Bearing Unit delivers high-strength shaft retention for 30 mm shafts under continuous dynamic loads.
Technical Specifications
| Inner Diameter (Bore) | 30 mm |
| Overall Height | 84 mm |
| Housing Width | 50 mm |
| Bolt Hole Centre Distance | 66 mm |
| Bearing Width (Total) | 38.1 mm |
| Housing Material | Cast Iron |
| HSN Code | 84832000 |
Applications
Material handling, bottling plants, and power transmission shafts.
| Inner Diameter | 30 mm |
|---|
