GMC UCHB Hanger Unit Pillow Block Bearing Series with Housing (20mm - 50mm Bore)
As low as
₹272.80
was
₹396.80
| Model | Overall height | Housing overall width | Mounting bolt | Bearing width, total | Inner diameter |
|---|---|---|---|---|---|
| GMC UCHB 204 | 96 mm | 64 mm | 3/4" | 31 mm | 20 mm |
| GMC UCHB 205 | 103 mm | 78 mm | 3/4" | 34 mm | 25 mm |
| GMC UCHB 206 | 103 mm | 78 mm | 3/4" | 38.1 mm | 30 mm |
| GMC UCHB 207 | 116 mm | 92 mm | 3/4" | 42.9 mm | 35 mm |
| GMC UCHB 208 | 121 mm | 96 mm | 3/4" | 49 mm | 40 mm |
| GMC UCHB 209 | 136 mm | 118 mm | 3/4" | 49.1 mm | 45 mm |
| GMC UCHB 210 | 142 mm | 118 mm | 3/4" | 51.6 mm | 50 mm |
Availability:
In stock
Only %1 left
SKU
GMC-UCHB-PARENT
Product Overview
The GMC UCHB Hanger Unit Bearing Series offers GMC cast iron suspended hanger bearing units from 20 mm to 50 mm.
Available Sizes & Specifications
| Model | Overall height | Housing overall width | Mounting bolt | Bearing width, total | Inner diameter |
|---|---|---|---|---|---|
| GMC UCHB 204 | 96 mm | 64 mm | 3/4" | 31 mm | 20 mm |
| GMC UCHB 205 | 103 mm | 78 mm | 3/4" | 34 mm | 25 mm |
| GMC UCHB 206 | 103 mm | 78 mm | 3/4" | 38.1 mm | 30 mm |
| GMC UCHB 207 | 116 mm | 92 mm | 3/4" | 42.9 mm | 35 mm |
| GMC UCHB 208 | 121 mm | 96 mm | 3/4" | 49 mm | 40 mm |
| GMC UCHB 209 | 136 mm | 118 mm | 3/4" | 49.1 mm | 45 mm |
| GMC UCHB 210 | 142 mm | 118 mm | 3/4" | 51.6 mm | 50 mm |
Applications
Industrial machinery, screw conveyors, material handling, and power transmission equipment.
| Brand | GMC |
|---|
