UCHB Hanger Unit Series with Housing (20mm - 50mm Bore)

Name: UCHB Hanger Unit Series with Housing (20mm - 50mm Bore)
SKU: UCHB-PARENT
Price: 272.8 INR
Availability: InStock

As low as ₹272.80 was ₹396.80

Availability:

In stock

Only %1 left

SKU

UCHB-PARENT

The UCHB Hanger Unit Bearing Series provides durable cast iron suspended hanger bearing units across shaft sizes from 20 mm to 50 mm.

Model	Overall height	Housing overall width	Mounting bolt	Bearing width, total	Inner diameter
UCHB 204	96 mm	64 mm	3/4"	31 mm	20 mm
UCHB 205	103 mm	78 mm	3/4"	34 mm	25 mm
UCHB 206	103 mm	78 mm	3/4"	38.1 mm	30 mm
UCHB 207	116 mm	92 mm	3/4"	42.9 mm	35 mm
UCHB 208	121 mm	96 mm	3/4"	49 mm	40 mm
UCHB 209	136 mm	118 mm	3/4"	49.1 mm	45 mm
UCHB 210	142 mm	118 mm	3/4"	51.6 mm	50 mm

Screw conveyors, agricultural machinery, bulk material augers, and industrial transmission drives.
